PureH2 Pro: High-Purity PEM Water Electrolysis System (99.999% H2)
SDQY-H5
PEM electrolytic water hydrogen production equipment is a fully automatic, lightweight, highly efficient, energy-saving, safe, and environmentally friendly system based on proton exchange membrane (PEM) technology. The PEM pure water electrolysis system delivers high-purity hydrogen at 99.999%, ensuring a non-corrosive and pollution-free operation. It features intelligent PLC control with one-touch start and stop functionality, enabling high-purity hydrogen generation within five minutes of startup. Hydrogen output pressure (adjustable from 0 to 3 MPa) and production rate (0–100% adjustable) can be precisely controlled to meet varying operational demands. The system is designed for easy installation, user-friendly operation, and reliable performance. Equipped with communication interfaces supporting the Modbus TCP/IP protocol, it enables remote monitoring and data access for enhanced operational oversight.
Delivery
EXW
minimum order
1 piece
Supply Ability
5piece / Month
Country of Origin
China
Stock Time
100Day
Quantity
US $8,920.00
To
via
自有物流
Estimated Delivery on
8-15
The high-efficiency hydrogen production volume is stable
Pure water electrolysis hydrogen production equipment
The electrolytic cell adopts the new generation of independently developed zero-pitch, highly active PEM catalytic electrodes, combined with excellent mass transfer, heat transfer and chemical process performance of the bipolar multi-component structure. It has superior electrochemical properties, corrosion resistance, passivation resistance, etc. Hydrogen production capacity :0.5-200Nm3/h,Hydrogen generator
hydrogen purity :99.999%. The hydrogen production is highly efficient and stable, providing a fundamental guarantee for the long-term operation of the hydrogen production system.
The electrolytic cell adopts the new generation of independently developed zero-pitch, highly active PEM catalytic electrodes, combined with excellent mass transfer, heat transfer and chemical process performance of the bipolar multi-component structure. It has superior electrochemical properties, corrosion resistance, passivation resistance, etc. Hydrogen production capacity :0.5-200Nm3/h,Hydrogen generator
hydrogen purity :99.999%. The hydrogen production is highly efficient and stable, providing a fundamental guarantee for the long-term operation of the hydrogen production system.
Ready-to-use, safe and environmentally friendly
The system adopts a split safety structure design, with independent cabinet design for electrical control and hydrogen production. Safety explosion-proof certification provides protection, ensuring the safe operation of the system. Eliminate alkaline water, green and environmentally friendly.
Multiple purifications ensure purity
The pure water temperature remains constant, and the gas circulates for cooling. The patented gas-liquid separation technology, deoxidation, and drying reduce the gas dew point, ensuring that high-purity hydrogen meets the usage requirements of users.
Genuine materials, stable and reliable
The electrolytic cell and water and gas lines are all made of special materials with excellent oxidation resistance, hydrogenation resistance, leakage prevention and mechanical properties. The pipeline joints are sealed by welding or ferrules, which is safe, stable and reliable.
Intelligent control, worry-free and effortless
The PLC control system operates with a single button, providing all-round monitoring of parameters such as pressure, liquid level, and water temperature, and enabling digital management of the equipment. It can achieve remote monitoring and unattended operation, with lower operation and maintenance costs.
Multiple monitoring and security protection
The system integrates flowmeters to automatically track the gas consumption of the load. The automatic protection technology is safe and reliable. It integrates real-time monitoring of oxygen in hydrogen and hydrogen in oxygen to prevent leakage. The automatic protection functions such as hydrogen leakage, water shortage, overpressure and waterproof impact provide intelligent protection guarantees for the safe operation of the system.
